Reinforced THT Inductor PFC UPS Chargers

Product Overview

The 2504 THT High Current Inductor is a high-performance through-hole magnetic component designed for high-power electronic systems, featuring a mechanically reinforced shielded high current inductor structure and ultra-low DC resistance (RDC). As a core energy storage and filtering component, this 2504 HCF THT inductor is optimized for high current power conversion and energy storage scenarios, with a shielded magnetic design that minimizes electromagnetic interference (EMI) and a mechanically reinforced shell that enhances structural stability in vibration-prone industrial environments. With inductance values ranging from 1μH to 10μH, high rated current (up to 39A) and excellent saturation current performance, the 2504 ultra-low RDC THT inductor is the ideal choice for power supply manufacturers, new energy equipment developers and industrial electronic solution providers, widely applied in high current power supplies, solar inverters and power factor correction (PFC) circuits.

Core Advantages

Mechanically Reinforced Structural Stability

Adopting a one-piece mechanically reinforced molding process, the 2504 THT High Current Inductor has high structural rigidity and vibration resistance, effectively preventing coil loosening and magnetic core damage in harsh industrial environments such as factory equipment and vehicle-mounted power supplies. Its through-hole (THT) welding design ensures firm soldering with the PCB board, reducing contact resistance and improving the reliability of long-term operation.

Shielded Magnetic Structure for Low EMI

Equipped with a fully enclosed shielded magnetic core structure, the inductor effectively suppresses magnetic flux leakage, reduces EMI interference to surrounding components and avoids external magnetic field interference to its own performance. This design meets the EMC requirements of industrial electronic products, simplifying the EMI debugging process of customer products.

Ultra-Low DC Resistance (RDC) for High Efficiency

Utilizing high-conductivity copper wire and optimized coil winding design, the inductor achieves ultra-low DC resistance, significantly reducing I²R power loss during high current operation. This not only improves the energy conversion efficiency of power supply systems but also reduces component heating, extending the service life of the entire circuit system.

High Current Handling & Low Saturation Loss

With high rated current (1μH model up to 39A) and 30% saturation current (up to 33A), the 2504 THT High Current Inductor maintains stable inductance performance under high current load, avoiding inductance drop caused by magnetic saturation and ensuring the stability of power conversion and filtering circuits. Its high self-resonant frequency (up to 38MHz) adapts to high-frequency power conversion designs, expanding the application range of the product.

Technical Specifications

Typical Applications

High Current Power Supplies

Applied to industrial high-current DC-DC power supplies, server power supplies and electric vehicle on-board chargers, serving as the core energy storage and filtering component to ensure stable output under high current load and improve power supply efficiency.

Solar Inverters & Battery Chargers

Ideal for photovoltaic solar inverters, energy storage battery chargers and portable power stations, with high current handling capacity and low power loss adapting to the high-power energy conversion requirements of new energy systems, and vibration resistance suitable for outdoor installation environments.

Power Factor Correction (PFC) Circuits

Widely used in active PFC circuits of industrial rectifiers, air conditioners and high-power household appliances, effectively improving the power factor of the circuit, reducing harmonic pollution to the power grid and meeting the national power grid’s harmonic emission standards.

Uninterruptible Power Supplies (UPS)

Suitable for industrial and commercial UPS systems, providing energy storage and filtering during power switching, ensuring stable power supply for critical equipment such as data centers, medical devices and industrial control systems when the mains power is interrupted.

Certifications & Compliance

The 2504 THT High Current Inductor is manufactured in accordance with international high standards, with complete certifications and environmental compliance, including:

RoHS 2015/863: Compliant with the latest EU restriction of hazardous substances directive, lead-free and cadmium-free design;

REACH (EC) 1907/2006: All chemical substances meet the EU’s registration, evaluation and authorization requirements, no restricted substances;

Halogen-Free (JEDEC JS709B): Bromine and chlorine content meet the international halogen-free standard, suitable for high-end environmental protection electronic products;

Industrial EMC Standard: The shielded magnetic design meets the IEC 61000 EMC standard, reducing EMI interference and improving the electromagnetic compatibility of the whole machine.

Customization & Procurement

Customization Options

We provide professional customization services for the 2504 THT High Current Inductor according to customer’s circuit design requirements, including custom inductance values (0.5μH-20μH), current rating optimization, magnetic core material adjustment (ferrite/metal powder core) and custom pin length. For special application scenarios, we can also customize the shell material and heat dissipation structure.

Procurement Terms
