Characteristics:
This solution enables simple and fast design integration while reducing the number of external components and minimizing PCB footprint, making it a highly cost-effective choice. It eliminates the need for an optocoupler, ensuring stable and reliable long-term voltage regulation without aging-related performance degradation. Additionally, it allows shared external components across different output voltages, significantly simplifying custom power supply design. With a standardized reference circuit, only the transformer and two feedback components need to be adjusted, providing greater flexibility and efficiency in product development.
·Isolated power design
·Sensor interfaces
·Isolated telecom converters
·Power over Ethernet
Physical Propertie
| Order Code | VIN | Vout1 (V) | lout1 (A) | Vout2 (V) | lout2 (A) | Vout3 (V) | lout3 (A) | Vout4 (V) | lout4 (A) | Vaux (V) | L (μH) | n | lSAT (A) | LS (μH) | VT V(AC)) |
| INF-ER9.5-15μH | 5V(DC) | 5 | 0.1 | 5 | 0.1 | - | - | - | - | 5 | 15 | 1:1:1:1 | 1.5 | 0.6 | 1500 |
