Physical Propertie
| Order Code | L (nH) | Tol.L | Test Condition L | Qmin (%) | Test Condition Q | RDc max. (mΩ) | lR (A) | fres (GHz) |
| INF-4248-22nH | 22 | 5% | 150 MHz | 100 | 150 MHz | 4.2 | 3 | 3.2 |
| INF-4248-22nH | 22 | ±2% | 150 MHz | 100 | 150 MHz | 4.2 | 3 | 3.2 |
| INF-4248-27nH | 27 | 15% | 150 MHz | 100 | 150 MHz | 4 | 3.5 | 2.7 |
| INF-4248-27nH | 27 | ±2% | 150 MHz | 100 | 150 MHz | 4 | 3.5 | 2.7 |
| INF-4248-33nH | 33 | ±5% | 150 MHz | 100 | 150 MHz | 4.8 | 3 | 2.5 |
| INF-4248-33nH | 33 | ±2% | 150 MHz | 100 | 150 MHz | 4.8 | 3 | 2.5 |
| INF-4248-39nH | 39 | 15% | 150 MHz | 100 | 150 MHz | 4.4 | 3 | 2.1 |
| INF-4248-39nH | 39 | 12% | 150 MHz | 100 | 150 MHz | 4.4 | 3 | 2.1 |
| INF-4248-47nH | 47 | 15% | 150 MHz | 100 | 150 MHz | 5.6 | 3 | 2.1 |
| INF-4248-47nH | 47 | ±2% | 150 MHz | 100 | 150 MHz | 5.6 | 3 | 2.1 |
| INF-4248-56nH | 56 | 15% | 150 MHz | 100 | 150 MHz | 6.2 | 3 | 1.5 |
| INF-4248-56nH | 56 | ±2% | 150 MHz | 100 | 150 MHz | 6.2 | 3 | 1.5 |
| INF-4248-68nH | 68 | ±5% | 150 MHz | 100 | 150 MHz | 8.2 | 2.5 | 1.5 |
| INF-4248-68nH | 68 | ±2% | 150 MHz | 100 | 150 MHz | 8.2 | 2.5 | 1.5 |
| INF-4248-82nH | 82 | 45% | 150 MHz | 100 | 150 MHz | 9.4 | 2.5 | 1.3 |
| INF-4248-82nH | 82 | ±2% | 150 MHz | 100 | 150 MHz | 9.4 | 2.5 | 1.3 |
| INF-4248-100nH | 100 | ±5% | 150 MHz | 100 | 150 MHz | 12.3 | 1.7 | 1.2 |
| INF-4248-100nH | 100 | ±2% | 150 MHz | 100 | 150 MHz | 12.3 | 1.7 | 1.2 |
| INF-4248-120nH | 120 | ±5% | 150 MHz | 100 | 150 MHz | 17.3 | 1.5 | 1.1 |
| INF-4248-120nH | 120 | ±2% | 150 MHz | 100 | 150 MHz | 17.3 | 1.5 | 1.1 |
Technical Specifications
