EI Series High Voltage Frequency Transformer


Characteristics:
· EI-type with multiple size options, high-frequency working range: 10kHz~1MHz+ (divided
into 10kHz-50kHz, 50kHz-100kHz, 100kHz-500kHz,500kHz-1MHz, over 10MHz)

· Power rate coverage: <5W up to 500W-1000W (including 5W-10W, 10W-20W, 20W-50W, 50W
-100W, 100W-200W, 200W-500W)

· Usable as flyback/drive/control/inverter/SMPS transformer, highcurrent inductor

Options:
· Good magnetic performance,low magnetic leakage

· Low energy loss, strong interference immunity

Common Applications:

·Switching mode power supplies,chargers, inverters, lighting (pool/garden light included)

·Alarm systems, robots/automation equipment, servers,communication equipment

·Electric vehicles, medicalequipment

Availability:
